M-Theri A
The M-Theri A system is an integrated multitasking solution within the M-Thermal Arctic range, designed to provide thermal comfort in households where space limitations may pose a challenge and the system needs to be integrated into the home’s design. The included wired controller allows users to manage zones easily and intuitively.
R-32 Refrigerant
Compatible with Airzone
WIFI
Smart Grid Ready
ACS Unit
Modbus
Cooling and Heating
ACS Tank
Configuration via USB port
Fully Integrable
Measuring 600×600, the M-Theri A kit’s indoor unit can be integrated into bathroom and kitchen furniture, and naturally, storage rooms.
Efficiency and Durability
The M-Theri A kit’s integrated indoor unit is equipped with a stainless steel boiler, perfectly insulated with a 4.5 cm thick layer of polyurethane.
Smart and Flexible System
The system automatically regulates itself based on changes in outdoor temperature and the energy demands of the building or home, always delivering optimal results.
Water Output at 65°C
Delivery capacity up to 65°C at an outdoor temperature of +5°C and up to 60°C at an outdoor temperature of -15°C, ensuring thermal comfort in all circumstances and hot water storage at 60°C.
Great Ease of Installation, Startup, and Maintenance
The new USB port allows you to configure the device in seconds and perform diagnostics to minimize startup or maintenance time.
Full Integration with Airzone
The entire M-Thermal range is compatible with the Airzone controller, specifically designed for multi-zone air-to-water heat pump systems (underfloor heating, fan coils, radiators, etc.) and supports up to 32 different services. Full integration with the Airzone gateway: WiFi, Amazon Alexa, Google Assistant, BACnet, KNX, Modbus RTU, and much more.
CTE 2020 and CYPE
The solutions in the Arctic region comply with all European, national, and regional regulatory frameworks to qualify as renewable energy. They are also listed in the CYPE database to facilitate calculation and specification phases.
Smart Home and BMS
The included wired control provides a pleasant and intuitive user experience capable of meeting all types of zoning needs. The ability to control and monitor the installation using the MSmartLife app via Wi-Fi and its integration with Amazon Alexa and Google Assistant makes the user experience even more pleasant and, above all, more efficient. Direct integration with ModBus RTU systems is also possible.
